51.2V 100Ah 5.12Kwh product performance
Micro-grid application, Backup power, Outage protection, Power peak load shifting and peak-valley arbitrage, solar batteries for home
51.2V Series Parameters Table
|
Datasheet |
51.2V 50Ah |
51.2V 86Ah |
51.2V 100Ah |
|
T ype |
lithium battery |
lithium battery |
lithium battery |
|
Nominal voltage |
51.2V |
51.2V |
51.2V |
|
Battery Module |
2.56kwh |
4.4kwh |
5.12kwh |
|
Nominal Capacity/Energy |
50Ah/2.56wh |
86Ah/4.4kwh |
100Ah/5.12kwh |
|
Rated Capacity/Energy |
45Ah/2.3wh |
77.4Ah/3.96kwh |
90Ah/4.6kwh |
|
Operating Voltage |
47.2-56.8V |
47.2-56.8V |
47.2-56.8V |
|
Rated Charging/discharging current |
25A |
43A |
50A |
|
Max Charging/discharging current |
48A |
83A |
96A |
|
Over current protection |
49A |
86A |
98A |
|
Rated Charging/discharging power |
1.28kw |
2.2kw |
2.56kw |
|
Max Charging/discharging power |
2.5kw |
4.4kw |
5.02kw |
|
Battery Type |
Lithium lron Phosphate (LFP) |
Lithium lron Phosphate(LFP) |
Lithium lron Phosphate (LFP) |
|
Operative temperature range |
-10~50℃ |
-10~50℃ |
-10~50℃ |
|
Recommended operating temperature |
15℃~30℃ |
15℃~30℃ |
15℃~30℃ |
|
Cooling |
Natural cooling |
Natural cooling |
Natural cooling |
|
Efficiency of Discharge |
96~99%@1C |
96~99%@1C |
96~99%@1C |
|
Function |
|||
|
Installation |
Floor standing installation |
||
|
Ingress protection |
IP20 |
||
|
Alarm&protection |
Over Voltage, Under Voltage, Over Current, Over temperature, Short Circuit etc. |
||
|
Communication port |
RS232/CAN/RS485(Optional) |
||
|
Cell safety certification |
CE,IEC62619,UL1973,CEC,UN38.3 |
||
