Feature:
Good high temperature performance
Safe Lithium Iron Phosphate Technology
High energy density and conversion efficiency
Life Span: 2000 cycle times
Environmental Friendly, without any heavy metals
Complete with Battery Management System built-in
Can use AC and solar chargers for this system
Low self discharge rate
Easy installation, can be in standard cabinet or be wall-mounted
Built-in automatic protectionfor over-charge, over-discharge&over-temperature conditions
High energy density 120-130kwh/kg,evenhigh discharge rate , while maintaining high energy capacity.
Increased Flexibility : Modular design enables deployment
Good High Rate Discharging and Excellent Stability
Intelligent chip design, excellent battery's storage capacity
Applications：
The 5kw solar battery is applicable for industrial, commercial or residential purposes
Battery Modules or Units are connected from Wh up to Mwh for renewable energy system
Energy Storage System
Solar Energy Storage
Solar Street Lighting
Electric Vehicle ( EV)
Medical
Telecom
Robotic
UPS
|
Item |
Specification |
|
Type |
lithium battery |
|
Voltage |
51.2V |
|
Rated capacity |
100Ah (0.2C/25°C) (Min:98Ah) |
|
Energy |
4200wh |
|
Operating voltage range |
42V- 58.4V (Typical:51.2V) |
|
Charging voltage |
56.0V±1.0V |
|
Discharge cut-off voltage |
42V±2.0V |
|
Charging current |
20A |
|
Charging current(Max.) |
30A |
|
Continuous Current |
50A |
|
Discharge current(Max.) |
100A |
|
Months Self Discharge |
≤3.5% |
