51.2V Stackable Lithium Battery Benefit
High-Voltage All-In-One Stackable ESS Parameters Table
Model
SBS2.56K3-GL3
SBS5.12K3-GL3
Nominal Voltage(Vdc)
51.2
51.2
Nominal Capacity(Wh)
2560
5120
Working Voltage Range(Vdc)
129.6~516.6
129.6~350.4
Charge Voltage(Vdc)
56.16
56.16
Nominal Charge/Discharge Current(A)
25
50
Max.Charge/Discharge Current(A)
50
100
Peak Current(A)
100@3sec
200@3sec
Series Connection
3-10 pcs
3-6 pcs
Cycle Life
6000@80%DOD, 25℃/0.5C
Structure
Power Module Dimensions(mm)Weight(kg)
600*210*250/14
610*225*250/15
Battery Module Dimensions(mm)Weight(kg)
600*210*160/27
610*225*250/52
Lampstand Module Dimensions(mm)Weight(kg)
600*210*90/5
610*225*90/5.5
Top Cap Module Dimensions(mm)Weight(kg)
600*210*50/2.5
610*225*50/3
IP Rating
IP65
Installation
Stacked
Working Environment
Charge Working Temperature(C)
0~55
Discharge Working Temperature(C)
-20~60
Altitude(M)
＜2500
Humidity(RH)
5~95%( w/o condensing)
Communication
Communication Port
RS485,CAN
Display
SOC status indicator, LED indicator
Certification
CB,IEC62619,CE-EMC,CE-GPSD,UKCA, UL1973,UL9540A,EN62040,IEC62040; UN38.3,MSDS
Power up your energy storage game with compact size,
lightweight design, and effortless installation of standardized modules,
leveraging the advantages of high voltage.Effortlessly customize battery combinations to meet your energy storage needs.
