on & off grid solar system

12v 48v Lifepo4 Solar Lithium Battery 24v lithium ion battery 200ah

Higher Power : 24v lithium ion battery 200ah high discharge rate and high energy capacity Wider Temperature Range : -20℃~60℃
  • Goods Stock:

    10
  • Order(MOQ):

    10
  • Certificate:

    CE
  • Lead Time:

    20-30Days
  • Paymen:

    T/T.L/C.Paypal.Western Union


Introduction:

The lithium ironphosphate (Lifepo 4 ) is a type ofrechargeable battery based on the orriginal lithium ion chemistry ,created by the use of Iron (FE ) as a cathode material . LIFePO 4 cells have higher discharge current do not explode under extreme conditions and wegh less but have lower voltage and energy density  than normal Li-lion cells

Applications:

The 24v lithium ion battery 200ah battery is applicable for industrial , commercial orresidential purposes

Battery Modules or Units are connected from Wh up toMwh for renewable energy system

Energy Storage System

Solar Energy Storage

Solar Street Lighting

Electric Vehicle ( EV)

Medica

Telecom

Robotic

UPS


Technical Parameters
No Item Parameters
1.Performance Type lithium battery
Nominal voltage 51.2V
Rated capacity 50Ah (0.2C/25°C) (Min:48.5Ah) 100Ah (0.2C/25°C) (Min:97Ah) 150Ah (0.2C/25°C) (Min:147Ah) 200Ah (0.2C/25°C) (Min:194Ah)
Energy 2560Wh 5120Wh 7680Wh 10240Wh
Operating voltage range 44.8V~ 57.6V 44.8V~ 56.8V 44.8V~ 56.8V 44.8V~ 56.8V
Recommended charging voltage 56V~57.6V 56V~56.8V 56V~56.8V 56V~56.8V
Discharge cut-off voltage 44.8V 44.8V 44.8V 44.8V
Charging current(Max.) 50A 50A 50A 50A
Charging current limit in parallelconnection(programmable ON/OFF) 10A 10A 10A 10A
Continuous discharging current(Max.) 50A 50A 50A 50A
Discharge current(Max.) 55A(<3s) 55A(<3s)
Months Self Discharge ≤3.5%
Cycle Life >3500 cycles @0.2C 80%DOD
Efficiency of Charge ≥98% @0.2C
Efficiency of Discharge 96~99% @1C
2.Function Parallel Support (difference of Pack's voltage< 0.5V)
Parallel funtion Support 12 units in parallel
Alarm&potection Over Voltage, Under Voltage, Over Current, Over temperature, Short Circuit etc.
3.Working Condition Cooling mode Automatic cold and hot
Altitude ≤4000m
Humidity 15%- 75%
Operating temperature Charge 0°C~45°C@60±25% Relative Humidity
Dischage -10°C~45°C@60±25% Relative Humidity
Recommended                  operating                                    temperature Charge 15°C~40°C@60±25% Relative Humidity
Dischage 15°C~40°C@60±25% Relative Humidity
Storage -20°C~45°C@60±25% Relative Humidity
4.Mechanical
Specifications
Size (W*H*D) External Size (W*H*D) 483*400*133mm 483* 385*222mm 450×400×230mm 483×400×400mm
Package Size (W*H*D) 583*500*233mm 583*500*322mm 583*500*322mm 583*500*502mm
Weight Net Weight (kg) About 31kg About 49.5kg About 75kg About 105kg
Gross Weight (kg) About 35kg About 55kg About 85kg About 115kg
5.Other Display ByYou  Select (LCD)
Shell Metal/lBlack/White
SOC (optional) RS232/RS485/CAN
Water dust resistance IP30
Application Field: Telecommunication,Solar energy storage, Household energy storage etc.
