on & off grid solar system

Hybrid off grid inverter 5KVA Charger Inverters for Home

Off-grid inverters 5KVA Charger Inverters for Home
  • Type:

    Off-Grid
  • Certificate:

    EMC.ROSH.CE
  • Lead Time:

    20-30Days
  • Paymen:

    T/T.L/C.Paypal.Western Union


Feature:

1.Pure sine wave inverter
2.Built-in MPPT solar charge controller
3. Selectable input voltage range and frequency according to city power in your countrol
4. Charging current is setable according to your battery type
5.Configurable AC/Solar input priority via LCD setting
6.Compatible to mains voltage or generator power
7.Auto restart while AC is recovering
8.Overload and short circuit protection
9.Smart charging system optimizes battery performance
10.Cold start function
11.Parallel operation with up to 9 units

Model HF-M 5K
INVERTER OUTPUT&INPUT
Rated Power 5KVA/4000W
Output Waveform Pure Sine Wave
Input Voltage 230VAC
Selectable Voltage Range
170-280 VAC(For Personal Computers) 90-280 VAC(For Home Appliances)
Output Frequency Range
50Hz/60Hz(Auto sensing)
AC Output Voltage regulation(Batt. Mode) 230VAC±5%
Surge power 10KVA
Efficiency (Peak)
93%
Transfer Time
10 ms (For Personal Computers) 20 ms(For Home Appliances)
SOLAR CHARGER
Maximum PV Array Power 3000W
MPPT Range @ Operating Voltage 60-115VDC
Maximum PV Array Open Circuit Voltage 145VDC
Maximum Charging Current 80A
Standby Power Consumption 2W
BATTERY &AC CHARGER
Battery Voltage 48VDC
Floating Charge Voltage
54VDC
Overcharge Protection
60VDC
Maximum Charge Current
20A or 30A
